1. High current characteristics: self-developed alloy magnetic powder, high Isat saturation current, not easily saturated under heavy load

2. Low loss: Flat wide copper wire, small DCR, low heat generation, high power conversion efficiency

3. Stable performance: -40~125 ℃ wide temperature range, small fluctuation of high-frequency working condition sensitivity, good batch consistency

4. Excellent shielding: Fully enclosed magnetic circuit, low magnetic leakage, low EMI interference, easy to pass electromagnetic compatibility testing

5. High reliability and quietness: Integrated die-casting structure, no abnormal noise, suitable for high-power power supplies in vehicles, industrial control, and servers
