TDS DownloadProduct Introduction
Characteristics of I-shaped inductor DLGBX0810
1. Balanced Size and Current Bearing Capacity
The 0912 moderate size features upgraded core volume, delivering higher current tolerance than tiny inductors while retaining space-saving advantages, adapting to medium-current compact circuit design.
2. Low Flux Leakage Design
Adopts full dense winding technology to minimize magnetic flux leakage, effectively reducing electromagnetic interference to surrounding components and improving overall circuit stability.
3. Excellent Continuous Operation Stability
Premium enameled wire and reinforced winding process ensure no parameter drift during long-duration continuous power operation, supporting stable long-term equipment operation.
4. High Compatibility for Circuit Matching
Strict dimensional tolerance control and standardized electrical parameters enable perfect compatibility with mainstream medium-frequency power conversion and filtering circuits, easy for mass production and replacement.
I-shaped inductor DLGBX0912 application areas
1. AI & Edge Computing Devices
Ideal for compact VRM power modules and edge computing hardware, stabilizing current output and suppressing high-frequency interference for intelligent computing boards.
2. New Energy Micro-storage Systems
Suitable for portable energy storage modules and mini photovoltaic power supply units, delivering steady inductance performance for efficient energy conversion.
3. Intelligent Vehicle Mini Electronics
Applied for vehicle ambient light control, on-board small sensing modules and car wearable accessories, adapting to vehicle anti-vibration and wide-temperature working conditions.
4. Smart IoT & Wireless Terminals
Perfect for IoT sensor nodes, wireless signal transceivers and low-power smart gateway equipment, ensuring stable signal filtering and voltage regulation.
Single-line Overview
Widely adopted in edge computing, micro energy storage, intelligent vehicle electronics and IoT wireless terminal industries.
DLGBX Series
List of package dimensions for I-type inductor DLGBX
| Type | ΦA | B(max) | C(min) | E | F |
|---|---|---|---|---|---|
| DLGBX0406 | 4.5±0.5 | 7.0 | 10 | 0.6 | 2.0 |
| DLGBX0608 | 6.5±1.0 | 10.0 | 10 | 0.6 | 3.0 |
| DLGBX0810 | 8.5±1.0 | 12.0 | 10 | 0.6 | 5.0 |
| DLGBX0912 | 9.5±1.0 | 14.0 | 10 | 0.6 | 5.0 |
| DLGBX1010 | 12.0(max) | 12.0 | 15 | 0.8 | 6.0 |
| DLGBX1012 | 12.0(max) | 16.5 | 15 | 0.8 | 6.0 |
| DLGBX1016 | 12.0(max) | 21.0 | 15 | 0.8 | 6.0 |
| DLGBX1212 | 14.0(max) | 16.5 | 15 | 0.8 | 7.5 |
| DLGBX1820 | 18.0(max) | 20.0 | 28 | 1.0 | 10.0 |
*Note: Dimensions can be customized according to customer requirements
I-shaped inductor DLGBX package size diagram
