Industry: Consumer Electronics   Part No.: GSHM0602MT6R8-V

Customer Challenge

A consumer-electronics customer faced a tough component-selection conflict. Their PCB footprint was locked at 6×6 mm, with a strict maximum component height of 2 mm and 3.5 A operating-current requirement.

Off-the-shelf 0603 molded power inductors could satisfy the 3.5 A current demand, but their body height exceeded the mechanical limit and could not fit the end-device housing. No standard part balanced footprint, height and current at the same time. Redesigning PCB layouts would bring extra engineering cost and project schedule delays.

Gujing Solution

Gujing’s technical team delivered a fast-track customized solution with GSHM0602MT6R8-V, avoiding PCB revision for the customer.

· Retain original 6×6 mm PCB pad, no layout change needed, saving engineering re-design time and costs

· Strictly controlled maximum height of 2 mm, perfectly matching compact mechanical constraints

· Achieves 3.5 A rated current, delivering current-handling capability equivalent to standard 0603 size, without sacrificing electrical performance

· Optimized custom scheme with competitive pricing and stable leadtime; no exorbitant nonrecurring tooling cost or extended waiting period

Gujing Core Competitive Advantages Highlighted

1. Application-oriented custom capability Resolve conflicts between mechanical space constraints and electrical indexes. Optimize component thickness while keeping the original PCB footprint, helping customers skip costly board rework and shorten project cycles.

2. Performance-first design philosophy Down-sized body does not mean degraded performance. We maintain large-size-level current-carrying capacity, ensuring stable working performance for end products.

3. Cost-&-delivery-friendly customization Unlike traditional custom solutions that come with high costs and long lead-times, Gujing leverages 23-years of magnetic-component experience and 20,000+ magneticcore formulas to provide feasible custom solutions suitable for mass-production. Balancing performance, cost and supply stability for customers.

4. Rapid technical support response Technical team quickly evaluates conflicting specs and proposes feasible device solutions, accelerating customers’ product validation progress.

Customer Outcome

The customer successfully adopted GSHM0602MT6R8-V for mass production. The project avoided PCB modification, met compact-structure requirements, kept target electrical performance, and achieved controllable cost and delivery schedule.
