Is PCBA space tight? Gujing has 23 years of experience and provides customized magnetic ring inductor pins

In the design of compact electronic products, PCBA space is precious. The pin arrangement of magnetic ring inductors often becomes a key constraint on layout - the fixed pin spacing of standard components often conflicts with the specific installation space, forcing installation not only occupies the space of adjacent devices, but also may affect circuit performance.

Gujing Electronics has been deeply involved in inductor manufacturing for 23 years. In response to this pain point, Gujing has recently collaborated with customers in the photovoltaic new energy industry to develop a magnetic ring inductor for their new projects. Gujing provides one-stop exclusive customization services, using special bent pins to accurately adapt and solve installation problems in limited spaces.

1、 Pin layout: key factors affecting space and performance

The pin layout of magnetic ring inductors is directly related to:

Space utilization: Improper foot spacing and row spacing waste board surface area, which may lead to re layout;

Electrical performance: Irregular bending or spacing may introduce parasitic parameters, affecting stability;

Production compatibility: It is necessary to avoid interference with peripheral components during soldering.

Standardized products are difficult to match changing scenarios, and customization has become an inevitable choice for efficient use of space.

2、 Customized solution for Gujing: precise adaptation, worry free performance

Based on the experience and technological accumulation of the 23rd generation, Gujing provides a full process solution from design to production:

1. Collaborative design of parameters

Our engineering team will recommend the optimal pin spacing and row spacing solution based on your circuit requirements, installation space, and surrounding layout. Whether it is compressing the spacing to adapt to narrow areas or adjusting the layout to avoid high-level components, precise matching can be achieved, maximizing the use of every millimeter of space.

2. Precise bending process

With a mature process database, we strictly control the bending radius and stress of different wire diameters and coatings to ensure:

Accurate size in accordance with the design;

Do not damage the insulation layer of the enameled wire;

Maintain the mechanical strength of the pins;

Ensure stable and unaffected performance of magnetic cores and coils.

3. Production compatibility guarantee

At the same time as customization, we simultaneously consider:

The pin form is compatible with your soldering process;

Matching tolerance with PCB aperture;

Reserve reasonable gaps for peripheral devices to avoid interference.

3、 Gu Jing's heritage: 23 years of intelligent manufacturing experience, continuous innovation

Case library supports rapid response: serving customers in multiple fields such as automotive electronics, industrial power supplies, and new energy, handling a large number of special customized needs, and able to quickly provide reliable solutions.

Following market demand iteration: We continuously optimize materials and processes to ensure that customized services not only solve installation problems, but also align with the development trend of high-performance and high reliability circuits.

One stop technical service: from solution design to mass production, providing technical collaboration throughout the process, becoming an extension of the customer's R&D team, and providing systematic support.

Conclusion

When standard inductors cannot meet your spatial layout, there is no need to compromise performance or design rationality.

Contact Gujing: Through pin specific customization, we seamlessly integrate magnetic ring inductors into your design, overcoming installation challenges in limited spaces and facilitating efficient product integration.

Breaking through spatial limitations, starting with a custom-made inductor from Gujing.
